Rotary Welding Robot, MIG Welder

MIG automatic welding machine

Xuzheng MIG rotary welding robots are typically used in MIG welding process for producing weld joints on metal workpieces. By rotating welding torch, the workpiece can be kept still, thus to implement welding process of water inlets or other workpieces.

MIG welding method brings a number of characteristics, such as low processing cost, easy to remove oxide film, resulting remain welding quality at a high level. It is applicable to nearly all kinds of metals, especially pure aluminum, aluminum alloy, copper, copper alloy and stainless steel.

MIG rotary welding robots are widely used in processing of auto parts, air tanks, fire extinguishers, wheel rims, etc.

Specifications

ITEM	XZZQH-300	XZZPH-500	XZZQH-1000
Input Power	220V 50HZ	220V 50HZ	380V 50HZ
Rated Power(KW)	14	14	14
Air Pressure Range(Mpa)	0.1～0.6	0.1～0.6	0.1～0.6
Work-piece Diameter(mm)	100～300	50～500	100～1000
Work-piece Length(mm)	30～1000	20～500	30～1000
Dimension-LengthWidthHeight(mm)	10008002300	600700700	15008002000
Weight(Kg)	350	300	800

Xuzheng not only provides our standard seam welders in stock, but also can manufacture custom models depending on your specific welding needs, such as material to be welded, pipe diameter, seam length, etc.
